Nexans JTS – Welcome in the new Era of the Heat-Shrinkable Joint!

Apr 17, 2021

Nexans launches the JTS, its new heat-shrinkable joint with triple layer tube. The triple layer tube represents a technical innovation that allows jointers to heat only 1 tube instead of 3 for 12 to 24 kV applications, and 2 tubes instead of 3 for 36 to 42 kV applications. The Nexans JTS then reduces complexity and the time to install the joint, while improving the quality of the global connection by reducing its operations.

The new range of Nexans JTS heat-shrinkable medium-voltage straight joints is compatible with single- or three-core polymeric cables with copper wire screen, copper tape screen or with Aluminum tape screen.

The new Nexans JTS Heat-Shrinkable Joint - Features & Benefits

  • Tube nesting / positioning and parking issues eliminated => typical jointing errors eliminated
  • Only one tube to shrink for the 3 functions (stress control – insulation - conductive) for voltage classes 12/17 & 24 kV
  • Only two tubes to shrink for the 3 functions (stress control - insulation - conductive) for voltage classes 36 & 42 kV
  • Reduced installation time / training time, with standard cable preparation work
  • Simplified stress control with 2-layer plate as used with Nexans cold shrink joints => no need to conform the mastic before shrinking the tube
  • Design adapted for all type and brands of mechanical / crimping connectors
  • Standard screen continuity with a copper stocking => simplify and reduce the installation time

The new Nexans JTS Heat-Shrinkable Joint - Resume

  • Short and slim design
  • Quick and easy to install
  • Excellent insulating properties
  • Advanced screen connection and armor continuity
  • Heavy wall tubing for high mechanical strength and impact resistance
  • Proof against water penetration and chemicals aggression
  • Stabilized UV protection
  • Halogen-free material content
  • Compliant to reach regulations
  • Premium technical support
  • Made in EU
