IEC LV, XLPE Insulation, SWA, PVC 0.6/1 kV

Products

10x1.5

Nexans ref. 2D002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 10
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 900 kg/km
  • Nominal outer diameter: 20.0 mm



10x2.5

Nexans ref. 2D003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 10
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 1110 kg/km
  • Nominal outer diameter: 22.0 mm



12x1.5

Nexans ref. 2E002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 12
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 710 kg/km
  • Nominal outer diameter: 19.0 mm



12x2.5

Nexans ref. 2E003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 12
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 890 kg/km
  • Nominal outer diameter: 21.0 mm



19x1.5

Nexans ref. 2F002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 19
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 930 kg/km
  • Nominal outer diameter: 22.0 mm



19x2.5

Nexans ref. 2F003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 19
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 1300 kg/km
  • Nominal outer diameter: 25.0 mm



24x1.5

Nexans ref. 2I002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 24
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 1250 kg/km
  • Nominal outer diameter: 25.0 mm



24x2.5

Nexans ref. 2I003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 24
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 1590 kg/km
  • Nominal outer diameter: 28.0 mm



2x1.5

Nexans ref. 22002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 300 kg/km
  • Nominal outer diameter: 13.0 mm



2x10

Nexans ref. 22010BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 10 mm²
  • Approximate weight: 700 kg/km
  • Nominal outer diameter: 18.0 mm



2x120

Nexans ref. 22120BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 120 mm²
  • Approximate weight: 3460 kg/km
  • Nominal outer diameter: 36.0 mm



2x150

Nexans ref. 22150BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 150 mm²
  • Approximate weight: 4110 kg/km
  • Nominal outer diameter: 39.0 mm



2x16

Nexans ref. 22016BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 16 mm²
  • Approximate weight: 1045 kg/km
  • Nominal outer diameter: 21.0 mm



2x185

Nexans ref. 22185BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 185 mm²
  • Approximate weight: 5330 kg/km
  • Nominal outer diameter: 44.0 mm



2x2.5

Nexans ref. 22003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 385 kg/km
  • Nominal outer diameter: 14.0 mm



2x25

Nexans ref. 22025BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 25 mm²
  • Approximate weight: 1080 kg/km
  • Nominal outer diameter: 21.0 mm



2x35

Nexans ref. 22035BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 35 mm²
  • Approximate weight: 1510 kg/km
  • Nominal outer diameter: 24.0 mm



2x4

Nexans ref. 22004BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 4 mm²
  • Approximate weight: 450 kg/km
  • Nominal outer diameter: 15.0 mm



2x50

Nexans ref. 22050BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 50 mm²
  • Approximate weight: 1900 kg/km
  • Nominal outer diameter: 26.0 mm



2x6

Nexans ref. 22006BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 6 mm²
  • Approximate weight: 540 kg/km
  • Nominal outer diameter: 16.0 mm



2x70

Nexans ref. 22070BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 70 mm²
  • Approximate weight: 2130 kg/km
  • Nominal outer diameter: 29.0 mm



2x95

Nexans ref. 22095BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 2
  • Conductor cross-section: 95 mm²
  • Approximate weight: 2890 kg/km
  • Nominal outer diameter: 33.0 mm



37x1.5

Nexans ref. 2M002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 37
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 1610 kg/km
  • Nominal outer diameter: 28.0 mm



37x2.5

Nexans ref. 2M003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 37
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 2555 kg/km
  • Nominal outer diameter: 32.0 mm



3x1.5

Nexans ref. 23002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 330 kg/km
  • Nominal outer diameter: 13.0 mm



3x10

Nexans ref. 23010BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 10 mm²
  • Approximate weight: 930 kg/km
  • Nominal outer diameter: 20.0 mm



3x120

Nexans ref. 23120BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 120 mm²
  • Approximate weight: 4760 kg/km
  • Nominal outer diameter: 41.0 mm



3x120+70

Nexans ref. 27120BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 120 mm²
  • Approximate weight: 5508 kg/km
  • Nominal outer diameter: 44.0 mm



3x150

Nexans ref. 23150BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 150 mm²
  • Approximate weight: 6070 kg/km
  • Nominal outer diameter: 46.0 mm



3x150+70

Nexans ref. 27150BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 150 mm²
  • Approximate weight: 6860 kg/km
  • Nominal outer diameter: 49.0 mm



3x16

Nexans ref. 23016BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 16 mm²
  • Approximate weight: 1240 kg/km
  • Nominal outer diameter: 22.0 mm



3x185

Nexans ref. 23185BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 185 mm²
  • Approximate weight: 7310 kg/km
  • Nominal outer diameter: 50.0 mm



3x185+95

Nexans ref. 27185BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 185 mm²
  • Approximate weight: 8350 kg/km
  • Nominal outer diameter: 54.0 mm



3x2.5

Nexans ref. 23003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 410 kg/km
  • Nominal outer diameter: 15.0 mm



3x240

Nexans ref. 23240BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 240 mm²
  • Approximate weight: 9135 kg/km
  • Nominal outer diameter: 55.0 mm



3x240+120

Nexans ref. 27240BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 240 mm²
  • Approximate weight: 10440 kg/km
  • Nominal outer diameter: 59.0 mm



3x25

Nexans ref. 23025BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 25 mm²
  • Approximate weight: 1640 kg/km
  • Nominal outer diameter: 24.0 mm



3x25+16

Nexans ref. 27025BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 25 mm²
  • Approximate weight: 2165 kg/km
  • Nominal outer diameter: 28.0 mm



3x300

Nexans ref. 23300BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 300 mm²
  • Approximate weight: 11015 kg/km
  • Nominal outer diameter: 60.0 mm



3x300+150

Nexans ref. 27300BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 300 mm²
  • Approximate weight: 12630 kg/km
  • Nominal outer diameter: 64.0 mm



3x35

Nexans ref. 23035BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 35 mm²
  • Approximate weight: 2030 kg/km
  • Nominal outer diameter: 27.0 mm



3x35+16

Nexans ref. 27035BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 35 mm²
  • Approximate weight: 2330 kg/km
  • Nominal outer diameter: 29.0 mm



3x4

Nexans ref. 23004BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 4 mm²
  • Approximate weight: 510 kg/km
  • Nominal outer diameter: 16.0 mm



3x400

Nexans ref. 23400BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 400 mm²
  • Approximate weight: 13760 kg/km
  • Nominal outer diameter: 67.0 mm



3x400+185

Nexans ref. 27400BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 400 mm²
  • Approximate weight: 16330 kg/km
  • Nominal outer diameter: 73.0 mm



3x50

Nexans ref. 23050BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 50 mm²
  • Approximate weight: 2520 kg/km
  • Nominal outer diameter: 30.0 mm



3x50+25

Nexans ref. 27050BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 50 mm²
  • Approximate weight: 2960 kg/km
  • Nominal outer diameter: 33.0 mm



3x6

Nexans ref. 23006BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 3
  • Conductor cross-section: 6 mm²
  • Approximate weight: 610 kg/km
  • Nominal outer diameter: 17.0 mm



3x70

Nexans ref. 23070BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 70 mm²
  • Approximate weight: 2860 kg/km
  • Nominal outer diameter: 33.0 mm



3x70+35

Nexans ref. 27070BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 70 mm²
  • Approximate weight: 3530 kg/km
  • Nominal outer diameter: 37.0 mm



3x95

Nexans ref. 23095BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 95 mm²
  • Approximate weight: 3940 kg/km
  • Nominal outer diameter: 38.0 mm



3x95+50

Nexans ref. 27095BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 3
  • Conductor cross-section: 95 mm²
  • Approximate weight: 4470 kg/km
  • Nominal outer diameter: 40.0 mm



4x1.5

Nexans ref. 24002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 4
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 370 kg/km
  • Nominal outer diameter: 14.0 mm



4x10

Nexans ref. 24010BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 4
  • Conductor cross-section: 10 mm²
  • Approximate weight: 1100 kg/km
  • Nominal outer diameter: 21.0 mm



4x120

Nexans ref. 24120BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 120 mm²
  • Approximate weight: 6450 kg/km
  • Nominal outer diameter: 47.0 mm



4x150

Nexans ref. 24150BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 150 mm²
  • Approximate weight: 7645 kg/km
  • Nominal outer diameter: 51.0 mm



4x16

Nexans ref. 24016BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 4
  • Conductor cross-section: 16 mm²
  • Approximate weight: 1430 kg/km
  • Nominal outer diameter: 24.0 mm



4x185

Nexans ref. 24185BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 185 mm²
  • Approximate weight: 9250 kg/km
  • Nominal outer diameter: 56.0 mm



4x2.5

Nexans ref. 24003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 4
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 470 kg/km
  • Nominal outer diameter: 16.0 mm



4x240

Nexans ref. 24240BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 240 mm²
  • Approximate weight: 11680 kg/km
  • Nominal outer diameter: 62.0 mm



4x25

Nexans ref. 24025BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 4
  • Conductor cross-section: 25 mm²
  • Approximate weight: 1970 kg/km
  • Nominal outer diameter: 27.0 mm



4x300

Nexans ref. 24300BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 300 mm²
  • Approximate weight: 14140 kg/km
  • Nominal outer diameter: 67.0 mm



4x35

Nexans ref. 24035BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 4
  • Conductor cross-section: 35 mm²
  • Approximate weight: 2470 kg/km
  • Nominal outer diameter: 29.0 mm



4x4

Nexans ref. 24004BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 4
  • Conductor cross-section: 4 mm²
  • Approximate weight: 580 kg/km
  • Nominal outer diameter: 17.0 mm



4x400

Nexans ref. 24400BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 400 mm²
  • Approximate weight: 18510 kg/km
  • Nominal outer diameter: 77.0 mm



4x50

Nexans ref. 24050BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 50 mm²
  • Approximate weight: 3150 kg/km
  • Nominal outer diameter: 33.0 mm



4x6

Nexans ref. 24006BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 4
  • Conductor cross-section: 6 mm²
  • Approximate weight: 825 kg/km
  • Nominal outer diameter: 19.0 mm



4x70

Nexans ref. 24070BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 70 mm²
  • Approximate weight: 3890 kg/km
  • Nominal outer diameter: 38.0 mm



4x95

Nexans ref. 24095BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Sector-shaped
  • Number of cores: 4
  • Conductor cross-section: 95 mm²
  • Approximate weight: 4930 kg/km
  • Nominal outer diameter: 42.0 mm



5x1.5

Nexans ref. 25002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 430 kg/km
  • Nominal outer diameter: 15.0 mm



5x10

Nexans ref. 25010BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 10 mm²
  • Approximate weight: 1270 kg/km
  • Nominal outer diameter: 23.0 mm



5x16

Nexans ref. 25016BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 16 mm²
  • Approximate weight: 1900 kg/km
  • Nominal outer diameter: 27.0 mm



5x2.5

Nexans ref. 25003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 530 kg/km
  • Nominal outer diameter: 17.0 mm



5x25

Nexans ref. 25025BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 25 mm²
  • Approximate weight: 2550 kg/km
  • Nominal outer diameter: 31.0 mm



5x35

Nexans ref. 25035BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 35 mm²
  • Approximate weight: 3170 kg/km
  • Nominal outer diameter: 34.0 mm



5x4

Nexans ref. 25004BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 4 mm²
  • Approximate weight: 680 kg/km
  • Nominal outer diameter: 18.0 mm



5x50

Nexans ref. 25050BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 50 mm²
  • Approximate weight: 4390 kg/km
  • Nominal outer diameter: 39.0 mm



5x6

Nexans ref. 25006BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 6 mm²
  • Approximate weight: 950 kg/km
  • Nominal outer diameter: 20.0 mm



5x70

Nexans ref. 25070BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 5
  • Conductor cross-section: 70 mm²
  • Approximate weight: 4980 kg/km
  • Nominal outer diameter: 44.0 mm



6x1.5

Nexans ref. 2B002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 6
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 595 kg/km
  • Nominal outer diameter: 17.0 mm



6x2.5

Nexans ref. 2B003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 6
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 845 kg/km
  • Nominal outer diameter: 19.0 mm



7x1.5

Nexans ref. 2C002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 7
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 440 kg/km
  • Nominal outer diameter: 16.0 mm



7x2.5

Nexans ref. 2C003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 7
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 650 kg/km
  • Nominal outer diameter: 19.0 mm



9x1.5

Nexans ref. 2K002BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 9
  • Conductor cross-section: 1.5 mm²
  • Approximate weight: 630 kg/km
  • Nominal outer diameter: 18.0 mm



9x2.5

Nexans ref. 2K003BXZVSB09BD0

  • Packaging: Unit
  • Conductor shape: Circular
  • Number of cores: 9
  • Conductor cross-section: 2.5 mm²
  • Approximate weight: 770 kg/km
  • Nominal outer diameter: 20.0 mm



Description

Description

Standards

  • International
    IEC 60332-1; IEC 60502-1
  • National
    FEWA-LV-UAE; SEWA-LV-UAE

Application


These power cables are used for electricity supply in low voltage installation systems.

They are well adapted to underground use in industrial applications where chemical and mechanical protections are needed (refinery areas, chemical plant…)



Design



  1. Conductor
    Stranded bare copper class 2 acc. to IEC 60228

  2. Insulation
    Cross Linked Polyethylene "XLPE"

  3. Inner Sheath or Bedding
    Lapped bedding or extruded PVC

  4. Armour
    Galvanized Steel Wire Armour "SWA"
  1. Outer Sheath
    Polyvinyl Chloride "PVC"

       Options :

             - Flame retardant : "CAT A, CAT B, CAT C" to IEC60332 or equivalent.

             - Ozone resistant.

             - Oil resistant.

             - Anti termite.



 Installation Conditions:

  1. Air Temperature : 30 Deg.
  2. Ground Temperature: 20 Deg.
  3. Soil Thermal Resistivity : 2.5 k.m/w
  4. Depth of lay : 0.7 m

 All dimensions have tolerance +- 7 %

Marking

no. of cores x conductor sizes mm2 Cu / XLPE / SWA / PVC 600/1000 V IEC 60502-1 MADE IN QATAR QICC-Nexans Year Meters

Custom marking available

Characteristics

Characteristics

Construction characteristics

Construction characteristics

Conductor material
Copper
Insulation
XLPE (Cross-linked Polyethylene)
Inner sheath
PVC
Armour type
Galvanized steel wires
Outer sheath
PVC
Colour
Black
Halogen free
No

Usage characteristics

Usage characteristics

Max. conductor temperature in service
90 °C
Short-circuit max. conductor temperature
250 °C
Flame retardant
Yes
Bending factor when laying
15 (xD)
Bending factor when installed
8 (xD)

Resources

Resources

Contact us

Topics on which you wish to get more informations:

Required fields*

Please check your entry and try again.

An email address must contain a single @

Personal data protector

You have the right to object to the processing of your personal data and/or their use for direct marketing or commercial purposes

Thank you!

Thanks for contacting us. We will be in touch with you shortly.

Error

An error occurred. Please try again.

Close

Contact us

Required fields*

Please check your entry and try again.

An email address must contain a single @

Personal data protector

You have the right to object to the processing of your personal data and/or their use for direct marketing or commercial purposes

Thank you!

Thanks for contacting us. We will be in touch with you shortly.

Error

An error occurred. Please try again.

Close
